BalconyDrain – shallow drainage
BalconyDrain is a range of shallow drainage channels and is not limited to use in balconies.
It can also be used in areas along the building line, for example, terraces, patios and other areas with restricted construction depth.
BalconyDrain is available in a range of depths and widths to suit site, user and hydraulic requirements:
- 85mm and 103mm wide channels
- Shallow 25mm and 40mm depth channels
BalconyDrain - product details
To download the BalconyDrain specification information, click here.
| Grate type | Compliance | |
|---|---|---|
| Affiner |  |  Wet pendulum: P1 Wet barefoot: A Compliant to AS 1428.1 Clause 4.4 (c) |
| 5 Star Heelsafe® Anti-Slip |  |  Wet pendulum: P4 Wet barefoot: C Compliant to AS 1428.1 Clause 4.4 (c) |
| Linéaire |  |  Wet pendulum: P1 Compliant to AS 1428.1 Clause 4.4 (c) |
| Tile |  |  The slip resistance of this grate depends on the infill material specified. Compliant to AS 1428.1 Clause 4.4 (c) |
| Grate type | Channel width (nominal) mm | Channel depth (nominal) mm | Specification code | DWG | RFA | |
|---|---|---|---|---|---|---|
| Affiner | 85 | 25 | S85-25-A |  |  |  |
| 103 | 25 | S103-25-A |  |  |  | |
| 103 | 40 | S103-40-A |  |  |  | |
| 5 Star | 103 | 40 | S103-40-5S |  |  |  |
| Linéaire | 85 | 25 | S85-25-L |  |  |  |
| 103 | 25 | S103-25-L |  |  |  | |
| 103 | 40 | S103-40-L |  |  |  | |
| Tile | 85 | 25 | S85-25-T |  |  |  |
| 103 | 25 | S103-25-T |  |  |  | |
| 103 | 40 | S103-40-T |  |  |  |
25mm deep channels
40mm deep channels
All dimensions are in mm
Need advice in specifying BalconyDrain?
ACO offers project specific services designed to make specification, ordering and installation easy.
The services deal with each project’s unique, hydraulic, structural, maintenance and spacial requirements. The service is fully documented and is offered free of charge and obligation.
